Appleton™ EXGJH and EXLK Flexible Couplings – Explosionproof Flexible Couplings
The Appleton™ EXGJH and EXLK flexible couplings are designed to provide explosionproof and dust-ignitionproof connections in electrical conduit systems, particularly suited for environments where vibration or movement challenges the use of rigid conduit. These flexible couplings are ideal for electrical distributors, lighting solutions, wire and cable installations, and switchgear suppliers requiring reliable, durable conduit fittings for hazardous locations. They serve as flexible alternatives to rigid conduit in difficult-bend situations, ensuring safety and integrity in industrial and hazardous environments.
- Material: Brass (end fittings), outer bronze braid with inner brass core and insulating liner for 1/2” thru 2” sizes
- Finish: Natural
- Product Weight: 1.59 lbs
- Certification: UL Listed (E34997), CSA Certified (065181), UL Standard 886 (1203), CSA Standards C22.2 No. 25 and No. 30
- Hazardous Location Ratings: NEC/CEC Class I, Division 1 & 2 (Groups A, B, C, D), Class II, Division 1 & 2 (Groups E, F, G), Class III; ATEX II 2 GD Ex d IIC Gb, Ex t IIIC Db, IP66
- Temperature Range: -40 °C to +150 °C (-40 °F to +302 °F)
- Thread Type: Accurately tapped, tapered threads for tight, rigid joints and ground continuity
- Design: Explosionproof, dust-ignitionproof, watertight flexible couplings
- Typical Sizes Available: 1/2” to 4” (with various flex lengths and diameters)
- Weight and Dimensions: See detailed dimension charts for bending radius and coupling sizes (e.g., 12” size coupling length 108.5 mm / 4.27 in)
Specifications
- Flexible design accommodates vibration and movement, replacing rigid conduit in challenging bends
- Smooth, rounded integral bushings protect conductor insulation from abrasion
- Heavy-duty construction resists mechanical abuse in industrial environments
- Electrical conductivity equivalent to rigid conduit, eliminating the need for bonding jumpers
- Interior insulating liner protects conductors under vibrating conditions
- EXGJH model: female end fittings with removable male nipples on both ends
- EXLK model: female end fitting with union on one end and female end fitting with removable male nipple on the other
- Watertight and suitable for wet locations
- Available options include stainless steel versions and custom lengths
Features
