MORRIS 39050 LOCKING TYPE PHOTOEYE 120V

MORRIS 39050 LOCKING TYPE PHOTOEYE 120V – Photocontrol Lighting Solutions

The MORRIS 39050 Locking Type Photoeye is a heavy-duty photocontrol designed for residential lighting systems, providing reliable dusk-to-dawn operation. It is commonly used in outdoor lighting fixtures to automate lighting control based on ambient light levels. This device is suited for electrical distributors, lighting solutions providers, wire and cable installers, and switchgear suppliers seeking durable, energy-efficient photocontrols with precise switching capabilities.

Specifications

• Voltage: 120V
• Tungsten Rating: 1000W
• Ballast Rating: 1800 VA
• Power Consumption: Below 0.9 Watts Average
• Temperature Range: -40°F to +150°F
• Contact Position at Night: Normally Closed
• Housing: Weatherproof Polycarbonate Cover with High Temp Polyester Base
• Switch Type: Single Pole, Single Throw
• Connector: Three Pole Lock-Type Connector with Solid Brass Legs
• Mounting: Typically mounts in dusk-to-dawn fixtures
• Lead Length: 6-inch color-coded leads with wiring diagram on control
• Threaded Nipple: 3/4" long, 3/8" threaded nipple & nut for 1/2" knockout (K.O.)
• Weight: Approximately 0.263 lbs

Features

• Heavy-duty thermal bi-metal switch with 30-45 second time delay to prevent unwanted lamp cycling caused by lightning or stray light
• Locking-type design for secure installation and tamper resistance
• Weatherproof construction suitable for outdoor environments
• Field-adjustable slide bar for turn-on level customization
• Compact cylindrical shape allowing installation in tight spaces
• Energy-efficient operation with low power consumption
• Compatible with a wide range of lighting fixtures and electrical systems

Downloads and Links

• Morris Photocontrols Catalog (PDF)
• 39050 Locking Type Photoeye Specification Sheet (PDF)
• Installation Instructions (PDF)
